Cabinet/G3
G3
  • Specification:
  • Constructed of heavy-duty steel for the ultimate server rack strength and stability Store servers, network and telecommunications equipment securely in this 19" solid steel rack
  • Reliable, space-saving solutions designed for organizing and securing server and networking applications. Suited for server rooms, wiring closets,manufacturing areas, warehouses, or anywhere where networking equipment needs to be protected. Ideal for housing LAN, WAN, phone, and voice mail equipment.
  • This modular cabinet helps save space in the server room and is designed to suit any server room footprint design, while housing any standard 19in rackmount equipment.
  • To help optimize ventilation, the cabinet offers steel mesh doors with wide perforation, and includes an integrated cable management system that helps keep the inside of the cabinet neat. Plus, the rack rail spacing is clearly marked, making it easy to plan and install equipment within the cabinet.
  • Includes lockable front and rear doors, and dual lock side doors
  • Front and rear doors easily removable and reversible
  • All steel, welded frame construction
  • Ships fully assembled
  • Sturdy, attractive, and secure server space
  • Arrives fully assembled and ready to go to work in your data center.
  • Removable side panels.
  • Vented top panel.
  • Generous cable access.
manufacture:Cabinet



Packing :
Product're wrapped with plastic wrap and PU foam inside to protect the corner areas.
Top panel & front door are protected by Styrofoam or PU plate. Thick & High Quality carton or wooden box.
 label on product.

Buyer can choose OEM or our standard:
We can manufacture the cabinet according to the customer special requirements also.
Color of Rack: Black / Beige or other color like Blue / Yellow / Red / Orange
More fan, Side panel of luck, W/O side panel etc….

Please contact with us if you like to change anything for other parts and make sure your order
also we have many difference type for your any new idea.
ItemHeightNumberWidth(mm)Depth(mm)Quantity
G347UG3-6647600600
G347UG3-6847600800
G347UG3-6947600900
G347UG3-60476001000
G347UG3-8647800600
G347UG3-8847800800
G347UG3-8947800900
G347UG3-80478001000
G342UG3-6642600600
G342UG3-6842600800
G342UG3-6942600900
G342UG3-60426001000
G342UG3-8642800600
G342UG3-8842800800
G342UG3-8942800900
G342UG3-80428001000
G337UG3-6637600600
G337UG3-6837600800
G337UG3-6937600900
G337UG3-60376001000
G337UG3-8637800600
G337UG3-8837800800
G337UG3-8937800900
G337UG3-80378001000
G332UG3-6632600600
G332UG3-6832600800
G332UG3-6932600900
G332UG3-60326001000
G332UG3-8632800600
G332UG3-8832800800
G332UG3-8932800900
G332UG3-80328001000
G327UG3-6627600600
G327UG3-6827600800
G327UG3-6927600900
G327UG3-60276001000
G327UG3-8627800600
G327UG3-8827800800
G327UG3-8927800900
G327UG3-80278001000
G322UG3-6622600600
G322UG3-6822600800
G322UG3-6922600900
G322UG3-60226001000
G322UG3-8622800600
G322UG3-8822800800
G322UG3-8922800900
G322UG3-80228001000
G318UG3-6618600600
G318UG3-6818600800
G318UG3-6918600900
G318UG3-60186001000
G318UG3-8618800600
G318UG3-8818800800
G318UG3-8918800900
G318UG3-80188001000




Features:
Meet IP20 Protection Grade
01.The items comply with ANSI/EIA; RS-310-D; IEC297-2; DIN41491(PART1); DIN41494(PART7);
01.GB/T3047.2-92 standard; compatible with ETSI standard.
02.High density vented undee single front door and double section rear door make the vented area
02.no less than 65% of the door area, the exquisite appearance.
02.The front door can choose international fashion color of tempered glass.
03.The side door can be installed and uninstalled quickly which make the working conveniently.
04.The cabinet can be installed castor and adjustable feet at one time which make the moving
04.and fixing easy.
05.The door hinge is interchangeable, top cable entry hole with rubber cover.
06.Material: SPCC high-quality cold roll steel
07.Surface finish: degreasing, pickling, phosphoric, static electricity, power coat.
08.Vertical mounting rails offer a square hole universal mount (EIA-310) for any brand server
09.Top and Bottom cover with ventilation for cooling.
10.Upper and bottom hole with install fans.
11.Adjustable rails 19”.
12.Quick release side panels with spring latch
13.Several lockable cable entrances on the top/bottom plate
14.Powder coat tough to reduce scratching and chipping.
15.Cage nuts and screws.
16.Excellent Air Ventilation Design with Optional Dual AC Cooling Fans
17.Split rear door minimizes the required access space behind the cabinet
18.Enforced Strengthen Glass Front Door with Security Key Lock
