USBMS-F v1.2
  • The USBMS adapter is designed for desktop/Embedded system that convert 3G/4G wireless Mini-Card to USB port.
  • You can insert your USB type minicard such as GSM, HSPA(3.5G), GPS, LTE cards to this adapter then plug to USB port through USB cable.
  • Standard SIM card Push connector is provided.
manufacture:Bplus

Function

  • USB mini type-B connection to desktop or notebook PC
  • Supports USB interface of Mini-Cards such as 2G GSM, GPRS, 3G, CDMA, WLAN, WWLAN, HSPA MODEM, GPS, 4G WiMAX, LTE, and Mini-Card to desktop PC.
  • Indicate ACCESS LED, POWER LED
  • Support SIM card Push-Push connector.
  • Support U.FL/IPX to SMA pigtail RF cable adapter
    • (Option) 824-984MHz; 1850-1990MHz SMA Antenna
    • (Option) 800-960MHz; 1710-2170MHz SMA Antenna
    • (Option) 700-960MHz; 1710-2700MHz SMA Antenna
    • (Option) 694-960MHz; 1710-2170MHz SMA Antenna
    • (Option) SMA or RP-SMA to U.Fl/IPX RF Cable
    • (Option) PCB Pad (Protect your desktop)
    • (Option) Super Cap. (For peak current)
    • (Option)3G CDMA / 4G LTE MiniCard





Specification

    • Case Dimension: 82 x 68 x 11mm (L x W x H)
    • PCI Express Mini Card Electromechanical Specification Revision 1.2
    • Universal Serial Bus Specification Revision 2.0
    • Full / Half -Mini Card dimension.
    • SIM Connector for CDMA HSDPA/HSUPA,UMTS, GSM, GPRS, EDGE
        •








Brief Taiwan 1 Taiwan 2 China
Dimension V1.2 Taiwan 1 Taiwan 2 China
Dimension V1.4 Taiwan 1 Taiwan 2 China
USBMS-E
Schematic
V1.2		 Taiwan 1 Taiwan 2 China
USBMS-E
Schematic
V1.4		 Taiwan 1 Taiwan 2 China
USBMS
V12-V14
Comparison		 Taiwan 1 Taiwan 2 China
USBMx Selection Guide Taiwan 1 Taiwan 2 China
